YCNH RAPID IMPACT COMPACTOR
Classification:
Product accessories:
- 产品描述
- 参数性能
- 应用领域
- 客户现场
-
- Commodity name: YCNH RAPID IMPACT COMPACTOR
★ This hammer is the new foundation construction machine for impacting soft foundation on its special hydraulic hammer technology. ★ It can be fixed fast on loader, excavator and crawler lift and with fine flexible, controllable and high efficiency and is a special and high speed impacting machine.
This hammer is the new foundation construction machine for impacting soft foundation on its special hydraulic hammer technology.
It can be fixed fast on loader, excavator and crawler lift and with fine flexible, controllable and high efficiency and is a special and high speed impacting machine.
It adopts numerical control, fully hydraulic driving, and impacting energy can be adjustable. It can be for plane, obliquity, steps, channel impacting, and its depth can be up to 3-10m. -
1.Features
1.1 Program control:
It can be single impacting and PLC impacting, energy presetting for single impacting and impacting energy and steps presetting;
It can automatic record the PLC impacting energy, times and single impacting energy, total running time and times. And it is easy for energy control and data collecting;
It can automatic monitor the impacting system.1.2 Simple and reliable:
It can use the loader and excavator hydraulic power, no needing other power, and connecting is simple, fast and reliable.
Its driving and control system is high integrated, with simple structure and easy maintenance.1.3 Easy and safety:
It can be fixed directly on loader, excavator and crawler lift, with good flexible, controllable and high efficiency, easy to use.
Its foot touch the foundation always and can avoid the potential danger and chip flying during dropping.2.Main technical parameter:
type
YCNH30
YCNH36
YCNH42
YCNH60
YCNH80
YCNH110
Nominal energy
kJ
30
36
42
60
80
110
Hammer body weight
t
2.5
3
3.5
4
5
7
striking Stroke
mm
200～1200
Working frequency (max.)
min-1
30～80
30～60
impacting plate diameter
mm
1000
1250
1500
Total weight
t
5.9
6.4
6.9
7.5
8.5
10.5
Over dimensions
Height
mm
3800
6800
Width
mm
1500
1680
Suggesting matching machine
50 loader
300～450 excavator
-
Each kinds of impacting plate, breaking device and pile guiding can be easy to changed, and then matched with loader, excavator and crawler lift for impacting, breaking and piling.
-
Anchor point positioning: text animation displacement to the corresponding position after adding anchor point links
Product Description
This hammer is the new foundation construction machine for impacting soft foundation on its special hydraulic hammer technology.
It can be fixed fast on loader, excavator and crawler lift and with fine flexible, controllable and high efficiency and is a special and high speed impacting machine.
It adopts numerical control, fully hydraulic driving, and impacting energy can be adjustable. It can be for plane, obliquity, steps, channel impacting, and its depth can be up to 3-10m.
Parameter Performance
1.Features
1.1 Program control:
It can be single impacting and PLC impacting, energy presetting for single impacting and impacting energy and steps presetting;
It can automatic record the PLC impacting energy, times and single impacting energy, total running time and times. And it is easy for energy control and data collecting;
It can automatic monitor the impacting system.
1.2 Simple and reliable:
It can use the loader and excavator hydraulic power, no needing other power, and connecting is simple, fast and reliable.
Its driving and control system is high integrated, with simple structure and easy maintenance.
1.3 Easy and safety:
It can be fixed directly on loader, excavator and crawler lift, with good flexible, controllable and high efficiency, easy to use.
Its foot touch the foundation always and can avoid the potential danger and chip flying during dropping.
2.Main technical parameter:
type | YCNH30 | YCNH36 | YCNH42 | YCNH60 | YCNH80 | YCNH110 | ||
Nominal energy | kJ | 30 | 36 | 42 | 60 | 80 | 110 | |
Hammer body weight | t | 2.5 | 3 | 3.5 | 4 | 5 | 7 | |
striking Stroke | mm | 200～1200 | ||||||
Working frequency (max.) | min-1 | 30～80 | 30～60 | |||||
impacting plate diameter | mm | 1000 | 1250 | 1500 | ||||
Total weight | t | 5.9 | 6.4 | 6.9 | 7.5 | 8.5 | 10.5 | |
Over dimensions | Height | mm | 3800 | 6800 | ||||
| Width | mm | 1500 | 1680 | ||||
Suggesting matching machine |
| 50 loader | 300～450 excavator | |||||
Application Areas
Each kinds of impacting plate, breaking device and pile guiding can be easy to changed, and then matched with loader, excavator and crawler lift for impacting, breaking and piling.
